Model 12100-22-W-R
, ships in: 3-7 business days
2-Inch Regressed LED Linear Wall Light
By Alcon Lighting
$249.95
Built to order
Loading...
This linear LED wall light features a sturdy extruded aluminum housing with a powder coat finish. The slim profile can tandem mount for continuous runs up to 40 feet at 120V or 100 feet at 277V. A regressed lens minimizes glare, providing a soft, focused light. The fixture offers flexible 3-position wattage (5W/7.5W/10W) and color temperature (30/35/40K) selection, and a 7-position DIP switch for customized light direction. With 0-10V dimming down to 10% and optional 90-minute emergency battery backup, this wall light suits offices, hotels and other modern commercial spaces.
Manufacturer
Alcon Lighting
Model
12100-22-W-R
Lead Time
Ships in: 3-7 Business Days
Return Policy
Assembled to Order. A 50% Restocking Fee May Apply.
Qualifications
Spec Grade, UL, Damp Location
Features
Color Temperature Selectable Switch, Wattage Selectable Switch, Light Direction Selectable Switch, Emergency Backup Battery
Dimming
0-10V
Wattage
10W/7.5W/5W per foot
Voltage
120-277V
Finish
White, Black
CCT
3000K, 3500K, 4000K
CRI
80+
Mounting
Wall
Light Direction
Direct/Indirect
Shape
Linear
Beam Spread
110°
Lumens per ft
400 lm/ft, 600 lm/ft, 800 lm/ft
Length
2 ft., 3 ft., 4 ft., 6 ft., 8 ft.
