Model SQ500

Luminis Syrios SQ500 Series 5" Square LED

By Luminis

Not available

UL IP66 CETL listed Damp-Location Rated
loader
Loading...

Luminis Syrios SQ500 Series 5" Square LED is a high performance luminaire for interior/exterior applications.

The Luminis Syrios blends with the traditional or contemporary architecture of schools, public spaces, office buildings, shopping centers and hospitals.

Mount: Fits on a 4” octagonal electrical box using 3 1/2” (89) C/C mounting holes or 2x4” (51x102) rectangular electrical box using 3.156” (80) C/C mounting holes.

Lens: Sealed cast aluminum lens frame. Clear tempered glass lens. Faceted specular aluminum reflector.

Color Quality: 80 CRI

LED: 4000K/80CRI. Optional 2700K, 3000K & 3500K.
Optional Amber LED for turtle sensitive areas.

Driver: 0-10V Dimming-ready

Input Voltage: 120/277V, 50/60Hz

Lifetime: 60,000 hours at 80% lumen maintenance

Ambient Operating Temperature: -30ºC/-22ºF to 55ºC/131ºF.

Emergency Lighting: Optional Emergency battery backup for lighting up to 90 minutes in event of power failure

Warranty: 5 Years product free from any defects in material and workmanship. Limited warranty voided if product is not installed according to manufacturer's guidelines.



  • Manufacturer
    Luminis
  • Model
    SQ500
  • Return Policy
    Built to order. Restocking fees apply.
  • Qualifications
    UL, IP66, CETL listed
  • Features
    Damp-Location Rated
  • Voltage
    120V, 277V
  • Finish
    White, Black, Silver, Grey, Bronze, Gun Metal, Custom RAL (Extended Lead Time May Apply)
  • CCT
    4000K, 2700K Residential Warm
  • CRI
    80+
  • Mounting
    Wall
  • Light Direction
    Direct Downlight, Direct/Indirect
  • Shape
    Square
  • Diameter
    12"
  • Beam Spread
    20° to 35
  • Additional options
    0-10V Dimming
