Alcon 14142-R-DIR Recessed Multiples 1-Inch Miniature LED Fixed Round Outdoor Light

cULus CA Title-24 Assembled in the USA Wet-Location Rated

Available SKU 14142-R-DIR

Lead Time
Ships In: 10-12 Weeks
Engineered to provide powerful surrounding light in small spaces, the recessed 12-volt LED product yields round direct downlight. Diecast metal construction is made for greater heat dissipation and built to last with a powder coat finish and rated for wet locations. Mounting of the magnetic 12-volt light can be daisy-chained for up to six fixtures to make installation easier. Available in a range of color temperatures. No frame required on remodel installation. 0-10V remote driver is standard, other remote drivers are available for an additional charge. Rated for wet locations. Height allows for 2x4 construction.
Manufacturer
Alcon Lighting
SKU
14142-R-DIR
Sale
On Sale
Lead Time
Ships In: 10-12 Weeks
Return Policy
Assembled to Order. A 50% Restocking Fee May Apply.
Regulations
cULus, CA Title-24 , JA8 Compliant, Assembled in the USA
Voltage
12V AC
Finish
White, Black, Bronze
Color Temperature
2700K Warm White, 3000K Soft White, 3500K Neutral White, 4000K Cool White, 5000K Day Light
Driver
0-10V
Configuration
1 Light (Recessed Multiple), 2 Light (Recessed Multiple), 3 Light (Recessed Multiple), 4 Light (Recessed Multiple), 5 Light (Recessed Multiple), IC-Rated Housing
Features
Wet-Location Rated
Mount Type
Recessed Flanged
Light Direction
Direct Downlight
Width
1"
Lumen Output Minimum
450
Lumen Output Max
675
Wattage
6 Watts
Beam Spread
28°, 38°, 50° Flood

Customize
