Model 12138

Vertical Lens LED Linear Pendant with Downlight

By Alcon Lighting
$399.95

Built to order

, ships in: 3-7 business days
Oversized Product Spec Grade UL Damp Location Color Temperature Selectable Switch Emergency Backup Battery
loader
Loading...
The Alcon Lighting 12138 Slim LED Direct and Indirect Linear Light delivers a sleek architectural profile with balanced, high-performance illumination. Its dual light distribution provides both direct and indirect output, ensuring uniform, glare-free lighting that enhances visual comfort and spatial quality. Ideal for conference rooms, open offices, retail spaces, and institutional environments, the fixture integrates seamlessly with T-grid or drywall ceilings. Damp-rated for reliability, it features a selectable CCT (3000K/3500K/4000K), 0–10V dimming, and an optional external emergency battery. Engineered with an extruded aluminum housing and polycarbonate optic, it combines durability with modern design, making it a versatile solution for commercial and architectural applications.
  • Manufacturer
    Alcon Lighting
  • Model
    12138
  • Lead Time
    Ships in: 3-7 Business Days
  • Return Policy
    Built to order. Restocking fees apply.
  • Qualifications
    Spec Grade, UL, Damp Location
  • Features
    Color Temperature Selectable Switch, Occupancy Sensor, Emergency Backup Battery
  • Dimming
    0-10V
  • Wattage
    40W, 60W
  • Voltage
    120-277V
  • Finish
    White, Black
  • CCT
    3000K, 3500K, 4000K
  • CRI
    80+
  • Mounting
    Pendant, Pendant Aircraft Cable
  • Light Direction
    Direct Downlight, Indirect Uplight
  • Shape
    Linear
  • Height
    7.55 Inches
  • Length
    4 Feet, 6 Feet
  • Beam Spread
    127.6°
  • Lumens per ft
    1000 lm/ft, 1100 lm/ft
  • Wattage per ft
    10.0 W/ft
  • Length
    4 ft.
