Product Highlights- The VT Volumetric Troffer combines the aesthetics and high performance with intelligent LED engines for applications - offices, schools, retail locations and hospitals. High-efficacy light engine delivers long life and excellent color, ensuring a superior quality lighting installation that is highly efficient and sustainable. Featured nLight controls system provides design flexibility and ease of installation and optimum energy savings.
- Rugged, one-piece cold-rolled steel coated polyester, painted after fabrication with embossed facets. Impact-modified, single clear acrylic diffuser provides excellent shielding and wide distribution. End plates include integral T-bar clips. Fixture may be mounted and wired in continuous rows. Total fixture height is only 4-3/8".
- Volumetric illumination is achieved by creating an optimal mix of light to walls, partitions, vertical and horizontal work surfaces — rendering the interior space, objects and occupants in a more balanced, complementary luminous environment. Linear faceted reflector cavity softens and distributes light into the space while minimizing luminous contrast between the fixture and ceiling. Sloped end plates provide a smooth, luminous transition between fixture and ceiling while enhancing the perception of fixture depth. Advanced optical film provides superior LED concealment and even illumination across the diffuser.
- Unique grid interfacing arrangement provides mounting into standard 1" and 9/16" tee bar or screw slot grids. 9/16" allows fixture trim to hang level with architectural ceiling tiles.
- nLight without lumen management
- Acrylic linear prismatic diffuser included
- 75 Watt Driver
Specifications
| Manufacturer |
Lithonia Lighting |
| SKU |
2VTL4 72L ADP D75 LP835 N100 |
| Technology |
LED |
| Regulations |
UL Listed |
| Warranty |
5 Year Manufacturer |
| General Applications |
Area Lighting |
| Voltage Options |
110V/120V AC |
| Light Color |
3500 Kelvin |
| CRI |
80+ |
| Life |
50,000 Hours |
| Features |
Dimmable, Emergency Backup |
| Dimensions |
2 ft. x 4 ft. |
| Product Type |
Troffer, Direct/Indirect, High & Low Bay, Flat Panels |
| Mount Type |
Recessed |
